C-3 C-5 C-6 C-7
The salt spreader is manufactured in seven sizes, from 0.6–7 m³. Models C-3, C-5, C-6 and C-7 can be supplied with moisturizing equipment that automatically reduces the salt volume by 30 %.
| Facts | C-3 | C-5 | C-6 | C-7 | Moisturising |
|---|---|---|---|---|---|
| Volume, m3 | 3,0 | 5,0 | 6,0 | 7,0 | 1,8 |
| Weight, kg | 1000 | 1300 | 1400 | 1500 | +200 |
| Spreading volume sand, g/m2 | 5-30 | 5-30 | 5-30 | 5-30 | -30% |
| Spreading volume salt, g/m2 | 50-200 | 50-200 | 50-200 | 50-200 | |
| Spreading width, m | 2-8 | 2-8 | 2-8 | 2-8 | |
| Hydraulic flow at 1000 rpm | 30/40 | 30/40 | 30/40 | 30/40 | |
| Hydraulic flow sand/salt, l/min | 60 | 60 | 60 | 60 | |
| Hydraulic pressure bar | 150 | 150 | 150 | ||
| Operating current, volt | 12, 24 | 12, 24 | 12, 24 | 12, 24 |
Surface treatment: Zinc metallised, primer and 2-component top coat
Extra equipment: Remote controlled spreading configuration, moisturising, mixer, hydraulic disc lift, side supports, screw unloader, extension frame, 2-chamber, bogie wheel or motor driven, side tanks etc
